How To Create Stepper Form Using Flutter Android Dart

admin_img Posted By Bajarangi soft , Posted On 05-11-2020

A material stepper widget that displays progress through a sequence of steps. Steppers are particularly useful in the case of forms where one step requires the completion of another one, or where multiple steps need to be completed in order to submit the whole form.The widget is a flexible wrapper. A parent class should pass currentStep to this widget based on some logic triggered by the three callbacks that it provides.

How To Create Stepper Form Using Flutter Android Dart

Stepper Form Builder

Step 1:  We cannot directly remove the time stamp from Stepper Form Builder but using the intl.dart package we can easily filter the date stamp from time stamp. So open your flutter project’s pubspec.yaml in code

dependencies:
  flutter:
    sdk: flutter
  flutter_form_builder: ^3.7.1


Step 2: After done saving the pubspec.yaml file, Open your flutter project root folder in Command Prompt or Terminal and execute flutter pub get command.

flutter pub get

Step 3: Open your project’s main.dart file and import material.dart and flutter_form_builder: ^3.7.1. dart package.
import 'package:flutter_form_builder/flutter_form_builder.dart';
import 'package:intl/intl.dart';


Complete Code For Stepper Form BUilder In Flutter
main.dart
import 'package:flutter/material.dart';
import 'package:flutter_form_builder/flutter_form_builder.dart';
import 'package:intl/intl.dart';

void main() => runApp(MyApp());

class MyApp extends StatelessWidget {
  @override
  Widget build(BuildContext context) {
    return MaterialApp(
      debugShowCheckedModeBanner: false,
      theme: ThemeData(
        textTheme: TextTheme(
          body1: TextStyle(fontSize: 16,color: Colors.black45,fontWeight: FontWeight.bold),
          display1: TextStyle(fontSize: 10),
        ),
      ),
      home: MyHomePage(),
    );
  }
}

class MyHomePage extends StatefulWidget {
  @override
  _MyHomePageState createState() => _MyHomePageState();
}

class _MyHomePageState extends State<MyHomePage> {
  var data;
  bool autoValidate = true;
  bool readOnly = false;
  bool showSegmentedControl = true;
  final GlobalKey<FormBuilderState> _fbKey = GlobalKey<FormBuilderState>();

  @override
  Widget build(BuildContext context) {
    return Scaffold(
      appBar: AppBar(
        backgroundColor: Colors.pink[800],
        title: Text("Stepper Form BUilder"),
      ),
      body: Padding(
        padding: EdgeInsets.all(10),
        child: SingleChildScrollView(
          child: Column(
            children: <Widget>[
              FormBuilder(
                key: _fbKey,
                initialValue: {
                  'date': DateTime.now(),
                  'accept_terms': false,
                },
//                autovalidateMode: true,
                child: Column(
                  children: <Widget>[
                    FormBuilderStepper(
                      decoration: InputDecoration(
                        enabledBorder: OutlineInputBorder(
                          borderRadius: BorderRadius.all(Radius.circular(12.0)),
                          borderSide: BorderSide(color: Colors.black26),
                        ),
                        focusedBorder: OutlineInputBorder(
                          borderRadius: BorderRadius.all(Radius.circular(12.0)),
                          borderSide: BorderSide(color: Colors.grey),
                        ),
                        contentPadding: EdgeInsets.all(4),
                          labelText: "Stepper",
                        labelStyle:   Theme.of(context).textTheme.body1,
                      ),
                      attribute: "stepper",
                      initialValue: 10,
                      iconActiveColor: Colors.pink[800],
                      step: 1,
                    ),
                    SizedBox(height: 10),
                  ],
                ),
              ),
            ],
          ),
        ),
      ),
    );
  }
}
